Dlink DNR-F5232-M8 32CH Network Video Recorder

Availablity:In stock

₹13,490.00



Check if the product is available for delivery to your location


Share


Dlink DNR-F5232-M8 32CH Network Video Recorder.

  • 32CH, 2 SATA NVR
  • Support up to 8MP IPC
  • Support H.265+/H.265/H.264+/H.264
  • Support Smart Playback & Analytics
  • Support 3G/4G Wi-Fi Connectivity
  • Support Google Drive & Dropbox Cloud storage
  • Support Onvif 2.6
  • Support 1CH Audio

Technical Specifications

Brand Dlink
Model No DNR-F5232-M8
Model Name 32CH Network Video Recorder
IP Video Input 32ch
Two Way Talk 1-ch, RCA
HDMI 1ch, resolution:4K(3840×2160)/30Hz,1920×1080/60Hz,1440×900/60Hz,1280 ×1024/60Hz, 1280×720/60Hz,1024×768/60Hz
VGA 1ch, resolution:1920×1080/60Hz,1440×900/60Hz,1280 ×1024/60Hz, 1280×720/60Hz,1024×768/60Hz
Audio Output 1-ch, RCA
Compression H.265+/H.265 /H.264+/H.264
Resolution 8MP/5MP/4MP/3MP/1080P/720P/D1/CIF /QCIF
Bit rate 64Kbps~10Mbps
Playback Mode Smart/ Normal/ Time Division/ Label/ Event/ Picture/ Log Playback
Decoding Capability 4CH@1080P(25fps)
Backup Mode USB Device/Network
Smart Detection Area Intrusion, Line crossing, Region Entrance /Region Exiting, Fast Moving, Object Missing, Unattended Object, Loitering
Smart Playback Line Crossing/Area Intrusion /Motion Detection
Cloud Storage Support
Cloud Upgrade Support
Incoming Bandwidth 256Mbps
Outgoing Bandwidth 256Mbps
Ethernet 1 RJ-45 10 /100/1000 Mbps self-adaptive Ethernet interface
Network Compatibility HTTP, HTTPS, TCP/IP, IPv4, UPNP, RTSP, UDP, SMTP, NTP, DHCP, IP Filter, DDNS, FTP, P2P, ONVIF 2.6
Smart Phone IOS (iPhone, iPad), Android (Phone, Pad)
SATA 2 SATA interface
Capacity Up to 8TB capacity for each HDD
USB Interface Front panel: 1 × USB 2.0 Rear panel: 1 × USB 2.0
Alarm In/Out 8CH/1CH
Power Supply DC12V 3.3A
Power Consumption ?10W (without HDD)
Dimension 326*243*52mm
Weight ?2.3Kg
Mobile Software D-Link Smart CCTV App
Desktop Software DSVS (D-Link Smart Video Surveillance)
System Requirement for Web Interface IE
